LED Power Supply parallel and series connections to the LED strip

There are two types of LED strip connections – parallel and series.

In a series connection. The plus and minus points of LED strips (or wires in the case of RGB or RGBW strips) are connected.

Only one cable comes from the power supply and connects the successive sections. This solution is undoubtedly practical. However, we must remember that we should not connect different types or colors of strips. This can significantly shorten the life – even the same kind of tape in different colors may have other power requirements.

In parallel connection. Each strip light has its cable connected directly to the power supply. This avoids voltage drops when tape lengths are long.

RGB LED strip lights connection led power supply

Series connection: Series connection of LED strips consists of connecting successive sections of strips together. This type of connection is recommended for short lengths of strips.

LED strip lights series connection led power supply

LED Driver use for LED embedded lighting application

Waterproof – LED strips are not only suitable for indoor projects. The waterproof LED light strips are IP65 rated and have silicone resin to protect the strip components from dust and moisture. Waterproof strips are more expensive, but necessary for some outdoor or near-water installations.

12v power supply for led lighting project

12 volt LEDs – the LED strip requires an Output Voltage 12V DC to operate. An AC/DC transformer is needed for home use, but this makes wiring the strips at home much safer. Rechargeable batteries also output DC, so you can easily use them to power LED strips.

Flexible LED strips are perfect for projects, but sometimes it’s hard to know where to start.

15W-60W DC 12V 24V LED Drivers

They are suitable for indoor use and ideal for use in the industrial field.

Power Supplies Universal AC input at full range

This LED power supply is equipped with overload protection, overvoltage, and a short circuit.

It is suitable for all LED strips and devices with constant DC 12V and DC 24V.

Outdoor LED Power supply used for LED products

Waterproof LED power supply 60W -300W

LED power supplies are the most critical part of the installation that supplies power to the LED lighting system. Thanks to the LED power supplies, the entire system is supplied with power reliably, safely, and without interference. The power supply provides the LED light sources with a constant current and the appropriate voltage.

AC input side 100-240V 175-240V

DC Output 12V 24V

Constant Current LED Drivers for LED architectural lighting installation

The common application uses high-power LEDs with constant current drivers, requiring a DC voltage input. Use for LED fixture cabinet lights, LED fixture lighting installation

30W LED driver

Dimmable power supply

Indoor Dimmable power supplies

Triac dimmer

alternating current

AC side 100-240V

dimmable power LED light source

TRIAC Dimmers

power supply dimmer light soure

Outdoor Dimmable power supplies

dimming control led lights brightness
0-10v and triac dimmable power supply
